htmlHeavy-duty side cabinet model 75: Technical specifications The Model 75 heavy-duty side cabinet measures 1110 x 1000 x 600 mm and is available in RAL 7035. It has a centre partition, solid sheet metal doors and two drawers with a height of 175 mm. Robust construction The extremely sturdy steel construction is welded and brazed at the corners, allowing a total load of 1.65 tonnes. The impact and scratch-resistant plastic coating ensures a long service life, while the body is finished in light grey. Optimum organisation The centre partition wall supports organisation under heavy loads. The front-mounted doors offer smooth fronts with an opening angle of over 200°, complemented by a continuous rod guide. Secure storage The double-walled reinforced doors are equipped with perforated and slotted panel doors as well as viewing window doors. A three-bolt security cylinder lock provides additional protection and group or master keys are available on request. Efficient utilisation of drawers The telescopic drawers offer full extension and can be loaded with up to 110 kg. Three drawer heights are available and can be retrofitted on request. Flexible shelves The galvanised shelves have a load capacity of 160 kg, optionally 200 kg, and can be adjusted in 25 mm increments, allowing flexible adaptation to different storage requirements.

htmlHeavy-duty side cabinet model 75 Dimensions: 1110 x 1000 x 600 mm, colour: RAL 7035. Technical specifications Centre partition for organised storage Total load: 1.65 tonnes Extremely sturdy, welded steel construction Impact and scratch-resistant plastic coating, body in light grey Smooth fronts with front-mounted doors, opening angle over 200° Continuous rod guidance Double-walled, reinforced doors with perforated and slotted panel doors or window doors Telescopic drawers with full-extension runners, load capacity: 110 kg Three drawer heights, can be retrofitted Galvanised shelves with a load capacity of 160 kg, optionally 200 kg Shelves can be adjusted in 25 mm increments Three-bolt security cylinder lock Additional group or master keys available on request Advantages for users Optimum organisation thanks to centre partition High load capacity for heavy loads Durable and robust construction Easy and safe handling thanks to smooth fronts and large opening angles Flexibility thanks to adjustable shelves and retrofittable drawers Increased security thanks to robust locking system

htmlProduct description: Heavy-duty side cabinet model 76 The Model 76 heavy-duty side cabinet offers a robust and durable solution for industrial applications. With dimensions of 1110 x 1000 x 600 mm and RAL 7035 colour, this cabinet is ideal for demanding storage requirements. Technical specifications Integrated centre partition for optimum organisation Solid sheet metal doors with an opening angle of over 200° for easy access Total load capacity of 1.65 tonnes Sturdy, welded steel construction with hard-soldered corners Impact and scratch-resistant plastic coating, body in light grey Telescopic drawers with full-extension runners, load capacity of 110 kg Galvanised shelves with a load capacity of 160 kg, optionally 200 kg Shelves can be adjusted in 25 mm increments Three-bolt security cylinder lock Advantages for the user Increased organisation thanks to additional centre partition Durability thanks to high-quality materials and workmanship Flexible customisation of the interior fittings as required Outstanding security thanks to robust locking system Easy access thanks to smooth fronts and front-mounted doors Additional options Additional group or master keys are available on request. Drawer heights can be retrofitted on request to meet individual requirements.

htmlHeavy-duty side cabinet model 76 Dimensions: 1110 x 1000 x 600 mm, colour: RAL 7035 Technical features Integrated centre partition for better organisation Double-walled doors for increased stability One shelf on the left and one shelf on the right Two drawers with a height of 175 mm Total load capacity: 1.65 tonnes Construction and material The cabinet consists of an extremely sturdy, welded steel construction with hard-soldered corners. The surface has an impact- and scratch-resistant plastic coating, the body is finished in light grey. Design and functionality Smooth fronts thanks to pre-fitted doors Opening angle of the doors over 200 Continuous linkage guide Double-walled, reinforced doors with perforated and slotted panel doors or window doors Drawers and shelves Telescopic drawers with full-extension runners Drawer load: 110 kg g.v.L. Three drawer heights, can be retrofitted on request Galvanised shelves with a load capacity of 160 kg or optionally 200 kg g.f.l. Adjustable in 25 mm increments Safety and accessories The cabinet is fitted with a three-bolt security cylinder lock. Additional group or master keys are available on request.

htmlLarge cupboard model 11 RAL 7035 Dimensions: 1950 x 1130 x 590 mm. The inside of the door is fitted with ®RasterPlan slotted/perforated panels and contains storage bins in the following sizes: 20 x size 4, 28 x size 6, 70 x size 7, 32 x size 8. High-quality workmanship and flexibility The high-capacity cabinets are characterised by their high-quality workmanship and spacious design. They integrate all the basic components of the ®RasterPlan programme, from perforated and slotted panels in the interior doors to flexible drawers and shelves. Modular design The ®RasterPlan open-plan cabinets are quick and easy to assemble thanks to their flexible and intelligent modular design. The cabinets consist of a shelving unit with ®RasterPlan perforated and/or slotted panel doors, window doors, drawers as well as a drawer partition set and galvanised shelves in three different depths. Robust construction The sturdy sheet steel construction has an impact and scratch-resistant plastic coating in light grey. Smooth fronts are guaranteed by pre-fitted doors with an opening angle of over 200°. The continuous rods and double-walled reinforced doors provide additional stability. Functional drawers and shelves The telescopic drawers allow full extension and can be retrofitted if required. The drawer load capacity is 50 kg g.v.l. Galvanised shelves offer a load capacity of 50 kg g.v.l. and are adjustable in 10 mm increments. Safety features A three-bolt security cylinder lock provides optimum protection. Additional group or master keys are available on request.

htmlLarge cupboard model 10 RAL 7035 Dimensions: 1950 x 1130 x 590 mm. The inside of the doors is fitted with ®RasterPlan perforated panels and contains storage bins in 9 x size 2 and 42 x size 6. High-quality workmanship and versatility These high-capacity cabinets have a particularly high-quality finish and offer a spacious solution that integrates all the basic components of the ®RasterPlan programme. The flexible modular design enables quick and easy assembly. Components and construction Shelving carcass with ®RasterPlan perforated and/or slotted panel doors Window doors and drawers Drawer divider set and galvanised shelves in three depths Sturdy sheet steel construction with impact and scratch-resistant plastic coating in light grey Smooth fronts thanks to pre-built doors with an opening angle of over 200° Double-walled, reinforced doors with continuous rod guide Functionality and adaptability The telescopic drawers offer a full-extension runner and can be retrofitted on request. Each drawer has a load capacity of 50 kg g.v.l. The galvanised shelves also carry 50 kg g.v.l. and are adjustable in 10 mm increments. Safety and options Fitted with a three-bolt security cylinder lock, additional group or master keys are available on request to meet your security requirements.

htmlLarge cupboard model 10 RAL 7035 Dimensions: 1950 x 1130 x 590 mm Inside of door ®RasterPlan slotted/perforated panels Including storage bins: 9 x size 2, 42 x size 6, 40 x size 7, 32 x size 8 High-quality workmanship The large storage units in the ®RasterPlan range integrate all the basic components, from perforated and slotted panels in the interior doors to flexible drawers and shelves. Modular design The ®RasterPlan open-plan wardrobes are quick and easy to assemble thanks to their flexible and intelligent modular design. Components Shelf carcass with ®RasterPlan perforated and/or slotted panel doors Inspection window doors Drawers with drawer divider set Galvanised shelves in three different depths Construction Sturdy sheet steel construction with impact and scratch-resistant plastic coating in light grey. Smooth fronts thanks to pre-fitted doors, opening angle over 200°. Technical details Double-walled reinforced doors with continuous linkage guide Telescopic drawers with full-extension runners, drawer load 50 kg g.v.l. Galvanised shelves with load capacity of 50 kg g.f.l., adjustable in 10 mm increments Three-bolt security cylinder lock Additional group or master keys available on request Advantages for users The large storage cabinets offer a robust and flexible solution for storing and organising materials. The high-quality workmanship and sophisticated design ensure durability and safety in industrial use.

htmlLarge cupboard model 10 RAL 7035 Dimensions: 1950 x 1130 x 590 mm. Equipped with viewing window doors and storage bins (9 x size 2, 42 x size 6). High-quality workmanship and flexibility The large storage cabinets in the ®RasterPlan programme offer seamless integration of all basic components. From perforated and slotted panels in the interior doors to flexible drawers and shelves as well as storage vision panels. Intelligent modular design Assembly is quick and easy thanks to the flexible and intelligent modular design. The cabinet consists of a shelving unit with ®RasterPlan perforated and/or slotted panel doors, viewing window doors and drawers, supplemented by a drawer partition set and galvanised shelves in three different depths. Robust construction The sturdy sheet steel construction has an impact and scratch-resistant plastic coating in light grey. The smooth fronts are made possible by pre-fitted doors with an opening angle of over 200°. Extended security features The doors are double-walled reinforced and the drawers are telescopic with full-extension runners. Retrofitting is possible on request. The drawer load capacity is 50 kg g.v.l., while the galvanised shelves also have a load capacity of 50 kg g.v.l., with adjustability in 10 mm increments. Security cylinder lock A three-bolt security cylinder lock is integrated as standard. Additional group or master keys are available on request.

htmlProduct description: Large cupboard model 11 RAL 7035 The Model 11 large capacity cupboard offers an excellent combination of functionality and quality. With dimensions of 1950 x 1130 x 590 mm and window doors, this cabinet is ideal for industrial applications. Components and equipment Including storage bins: 20 x size 4, 28 x size 6, 30 x size 7 Perforated and slotted panels in the inner doors Flexible drawers and shelves Sturdy sheet steel construction with impact and scratch-resistant plastic coating in light grey Modularity and adaptability The modular design enables quick and easy assembly. The cabinet consists of a shelving unit with perforated and/or slotted panel doors, window doors and drawers, supplemented by a drawer divider set and galvanised shelves in three depths. Technical details Opening angle of the doors over 200° Double-walled reinforced doors and side panels Telescopic drawers with full-extension runners, can be retrofitted Drawer load: 50 kg g.v.l. Galvanised shelves with load capacity of 50 kg g.f.l. and 10 mm grid adjustment Three-bolt security cylinder lock, additional keys on request Advantages for users The Model 11 larder unit offers a robust and durable solution for storage in industrial environments. The flexible interior design allows customisation to meet specific storage requirements, while the high-quality finish and security features ensure reliable use.

htmlLarge cupboard model 12 RAL 7035 Dimensions: 1950 x 1130 x 590 mm Inside of door Equipped with ®RasterPlan perforated panels, including storage bins in the following sizes: 5 x size 4, 14 x size 5, 28 x size 6, 50 x size 7. High-quality workmanship and space-saving design These spacious larder units combine all the essential components of the ®RasterPlan programme. From perforated and slotted panels in the interior doors to flexible drawers, shelves and storage bins. Modular design The ®RasterPlan high-capacity cabinets are quick and easy to assemble thanks to their flexible and intelligent modular design. The cabinets consist of a shelving unit with ®RasterPlan perforated and/or slotted panel doors, window doors and drawers, supplemented by a drawer partition set and galvanised shelves in three different depths. Robust construction Made of sturdy sheet steel construction, with impact and scratch-resistant plastic coating in light grey. The smooth fronts are achieved by pre-fitted doors with an opening angle of over 200°. Continuous rod guidance and double-walled reinforced doors provide additional stability. Functionality and adaptability Perforated and perforated/slotted panel doors as well as double-walled side panels offer flexibility. Telescopic drawers with full-extension runners can be retrofitted on request. Each drawer has a load capacity of 50 kg g.v.l. The galvanised shelves also have a load capacity of 50 kg g.v.l. and are adjustable in 10 mm increments. Safety Fitted with a three-bolt security cylinder lock. Additional group or master keys are available on request.

htmlLarge cupboard model 12 RAL 7035 Dimensions: 1950 x 1130 x 590 mm Inside door and equipment ®RasterPlan perforated/slotted panels Storage bins: 5 x size 4, 14 x size 5, 28 x size 6, 90 x size 7, 32 x size 8 Modular design and flexibility The high-capacity cabinets offer a high-quality finish and combine all the basic components of the ®RasterPlan programme. They are equipped with perforated and slotted panels in the interior doors, flexible drawers and shelves as well as storage bins. Assembly is quick and easy thanks to the intelligent modular design. Design features Sturdy sheet steel construction Impact and scratch-resistant plastic coating in light grey Smooth fronts with front-mounted doors, opening angle over 200° Continuous rod guidance Double-walled reinforced doors Drawers and shelves Telescopic drawers with full-extension runners, can be retrofitted Drawer load: 50 kg g.v.l. Galvanised shelves with load capacity of 50 kg g.f.l. Adjustable in 10 mm increments Security and key options The cabinet is fitted with a three-bolt security cylinder lock. Additional group or master keys are available on request.

htmlProduct description The large storage cabinet model 12 in RAL 7035 with the dimensions 1950 x 1130 x 590 mm offers a well thought-out combination of functionality and flexibility. Equipped with viewing window doors and a variety of storage bins (5 x size 4, 14 x size 5, 28 x size 6, 50 x size 7), this cabinet is ideal for industrial applications. Technical details Modular design for quick and easy assembly Shelf carcass with ®RasterPlan perforated and/or slotted panel doors Galvanised shelves in three depths, load capacity 50 kg g.f.l. Telescopic drawers with full-extension runners, load capacity up to 50 kg g.f.l. Sturdy sheet steel construction with impact and scratch-resistant plastic coating in light grey Opening angle of the doors over 200° for optimum access Double-walled, reinforced doors and side panels Three-bolt security cylinder lock, additional keys on request Advantages for the user The large capacity cabinet offers an optimum solution for storage and organisation in industrial environments. The modular design allows flexible customisation to individual requirements. The robust design and high-quality workmanship guarantee durability and reliability. The viewing window doors and the large selection of storage bins make it easier to keep track of and access stored materials. Additional information The cabinets can be retrofitted on request and are highly customisable. The galvanised shelves and telescopic drawers ensure efficient use of space. The security cylinder lock ensures that stored items are protected.

htmlLarge cupboard model 13 RAL 7035 Dimensions: 1950 x 1130 x 590 mm. Equipped with window doors and 21 storage bins size 2. These open-plan cabinets offer a high-quality finish and combine all the basic components of the ®RasterPlan programme. Flexibility and modularity The larder cabinets are equipped with perforated and slotted panels in the inner doors, flexible drawers and shelves as well as storage bins. Assembly is quick and easy thanks to the flexible modular design. Robust construction Made of sturdy sheet steel construction with impact and scratch-resistant plastic coating in light grey. The smooth fronts and pre-fitted doors offer an opening angle of over 200°. Safety features The high-capacity cupboards have full-length rod guides and double-reinforced doors. Perforated and perforated/slotted panel doors and double-walled side panels provide additional security. Optimised storage Telescopic drawers with full-extension runners and a load capacity of 50 kg. Galvanised shelves also offer a load capacity of 50 kg, adjustable in 10 mm increments. Security cylinder lock Fitted with a three-bolt security cylinder lock. Additional group or master keys are available on request.

htmlTechnical description of the large cupboard model 13RAL 7035 The large capacity cabinet model 13RAL 7035 with the dimensions 1950 x 1130 x 590 mm is a high quality solution for industrial storage requirements. The inside of the door is fitted with ®RasterPlan perforated panels and contains 21 size 2 storage bins. Modular design and flexibility This cabinet combines all the essential components of the ®RasterPlan range, including perforated and slotted panels in the inner doors, flexible drawers and shelves and storage bins. The modular design enables quick and easy assembly. Robust construction Made from a sturdy sheet steel construction, the cabinet has an impact and scratch-resistant plastic coating in light grey. The smooth fronts are ensured by pre-fitted doors with an opening angle of over 200°. Extended security features The enclosure has a continuous rod guide and double-walled, reinforced doors. The perforated and slotted panel doors as well as the side panels are also double-walled. A three-bolt security cylinder lock provides increased security, with the option of additional group or master keys. Optimised storage capacity The telescopic drawers offer full extension and are designed with a load capacity of 50 kg g.v.L. Galvanised shelves with a load capacity of 50 kg g.v.l. offer adjustability in 10 mm increments. This large capacity cabinet is ideal for industrial applications that require a robust and flexible storage solution. Retrofittable options are available on request to customise the cabinet to specific requirements.

htmlLarge cupboard model 14 RAL 7035 Dimensions: 1950 x 1130 x 590 mm. Equipped with viewing window doors and storage bins in various sizes: 9 x size 2, 5 x size 3, 14 x size 5, 14 x size 6, 10 x size 7. High-quality workmanship and flexibility The large storage cabinets in the ®RasterPlan programme offer first-class workmanship and generous storage space. They integrate all the basic components of the system, from perforated and slotted panels in the interior doors to flexible drawers and shelves. Modular design Thanks to the intelligent modular design, the ®RasterPlan open-plan cabinets are quick and easy to assemble. The cabinets consist of a shelving carcass with ®RasterPlan perforated and/or slotted panel doors, window doors and drawers, supplemented by a drawer divider set and galvanised shelves in three depths. Robust construction The sturdy sheet steel construction has an impact and scratch-resistant plastic coating in light grey. The smooth fronts and the front-mounted doors offer an opening angle of over 200°, supported by a continuous linkage system. Double security The doors are double-walled reinforced, with perforated and perforated/slotted panel doors as well as double-walled side panels. The telescopic drawers are fully extendable and can be retrofitted on request. Drawer load capacity is 50 kg g.v.l. Galvanised shelves also carry 50 kg g.v.l. and are adjustable in 10 mm increments. Safety lock A three-bolt security cylinder lock provides protection. Additional group or master keys are available on request.

htmlLarge cupboard model 14RAL 7035 Dimensions: 1950 x 1130 x 590 mm Interior fittings The inside of the door is fitted with ®RasterPlan perforated panels and contains storage bins in the following sizes: 9 x size 2, 5 x size 3, 14 x size 5, 14 x size 6, 10 x size 7. Modular design These high quality large capacity cabinets integrate all the basic components of the ®RasterPlan programme. They offer perforated and slotted panels in the interior doors, flexible drawers and shelves as well as storage bins. Assembly is quick and easy thanks to the flexible and intelligent modular design. Construction and material The high-capacity cupboard consists of a shelving unit with ®RasterPlan perforated and/or slotted panel doors, viewing window doors and drawers. This is supplemented by a drawer partition set and galvanised shelves in three different depths. The sturdy sheet steel construction has an impact- and scratch-resistant plastic coating in light grey. Functionality The smooth fronts are achieved by pre-fitted doors with an opening angle of over 200°. A continuous rod guide and double-walled reinforced doors provide additional stability. The perforated and perforated/slotted panel doors as well as the side panels are also double-walled. Drawers and shelves The telescopic drawers offer full extension and are designed for a load of 50 kg g.v.L. Galvanised shelves also have a load capacity of 50 kg g.v.l. and are adjustable in 10 mm increments. Drawers can also be retrofitted on request. Safety A three-bolt security cylinder lock protects the contents. Additional group or master keys are available on request.

htmlLarge cupboard model 14 RAL 7035 Dimensions: 1950 x 1130 x 590 mm Inside of door ®RasterPlan slotted/perforated panels Including storage viewing box: 9 x size 2, 5 x size 3, 14 x size 5, 14 x size 6, 50 x size 7, 32 x size 8 Advantages and benefits The large storage cabinets in the ®RasterPlan programme offer high-quality workmanship and spacious storage solutions. They integrate all the basic components of the programme, from perforated and slotted panels in the interior doors to flexible drawers and shelves. Flexibility and modularity Assembly is quick and easy thanks to the flexible and intelligent modular design. The cabinets consist of a shelving unit with ®RasterPlan perforated and/or slotted panel doors, window doors and drawers, supplemented by a drawer divider set and galvanised shelves in three depths. Robust construction The sturdy sheet steel construction has an impact and scratch-resistant plastic coating in light grey. The smooth fronts with front-mounted doors offer an opening angle of over 200° and a continuous rod guide. The double-walled, reinforced doors provide additional security. Drawers and shelves Telescopic drawers with full-extension runners can also be retrofitted on request and carry up to 50 kg g.v.l. Galvanised shelves have a load capacity of 50 kg g.v.l. and are adjustable in 10 mm increments. Safety A three-bolt security cylinder lock protects the contents. Additional group or master keys are available on request.

htmlLarge cupboard model 24 RAL 7035 Dimensions: 1950 x 1130 x 590 mm Inside of door: ®RasterPlan perforated panels Including 2 drawers at the bottom, equipped with storage bins: 20 x size 4, 21 x size 6, 20 x size 7. Integration of the ®RasterPlan programme These large storage cabinets combine all the basic components of the ®RasterPlan programme, from perforated and slotted panels in the inner doors to flexible drawers and shelves. Modular design They are constructed using a flexible and intelligent modular design that enables quick and easy assembly. Construction and materials The cabinet consists of a sturdy sheet steel body with ®RasterPlan perforated and/or slotted panel doors, viewing window doors and drawers. This is supplemented by a drawer partition set and galvanised shelves in three different depths. Surface coating The impact- and scratch-resistant plastic coating in light grey ensures a long service life. Door and drawer functions The smooth fronts with front-mounted doors offer an opening angle of over 200°. The continuous rod guidance and double-walled reinforced doors ensure additional stability. The telescopic drawers with full-extension runners can be retrofitted on request and offer a load capacity of 50 kg g.v.L. Shelves and safety Galvanised shelves with a load capacity of 50 kg g.v.L. and adjustable in 10 mm increments. Fitted with a three-bolt security cylinder lock. Additional group or master keys are available on request.
